Setup and operation guide for non-contact infrared thermometers distributed to stations. Each station gets two devices. Install starter batteries, wait 10 minutes for warm-up, switch to Fahrenheit using mode and +/-, then aim at the forehead from 2 inches away and press measure.
Questions this video answers
Two (one for station screening and one placed on the rescue truck).
Two starter batteries, screws, and a screwdriver.
Celsius.
Turn on (squeeze trigger), press mode until display shows F1, then use the +/− buttons to set Fahrenheit.
Approximately 10 minutes for warm-up.
Chapters
Very shortly you are all going to be receiving two non contact infrared thermometers at every station. One is to be used for station screening and the other one is going to be placed on the rescue truck at this time. These are commercially produced and very simple to put together.
We're going to go through that process right now. As you remove it from the box, you're going to find that it brings two starter batteries, the device itself and a bag with screws and a screwdriver. Now, I've removed that out of the way at this moment, but the batteries.
Are placed in the device following the.
Owner'S manual and secured with the screwdriver.
And a small screw here to keep.
It locked and closed so you don't lose the batteries in the middle of the process.
When you have the batteries in place, the device defaults to Celsius.
The manner in which you change the setting is that you turn the device on by squeezing the trigger.
It's going to note a failure because you're not pointing at anybody. And then you squeeze the or you push down on the mode button and once it switches to F1 on the back of the screen, you'll use the plus or minus right here to take.
It to Fahrenheit for the first use and when inserting new batteries, please wait 10 minutes for the warm up of the device. If the device is not used for a long time. Once you turn it on again, the device will test the room temperature first and will delay turning on for one to two seconds. Select the body mode. Aim towards the forehead from a distance of approximately 3 to 5 centimeters, about 2 inches. Press the measuring key. You will hear a beep and and then the temperature will display immediately following the second beep. Make sure that there's no hair, perspiration, cosmetics or cap covering the forehead.
Just remember to use all your proper PPE when you're using this device and to completely decontaminate it after each and every use. If you have any questions, refer to the owner's manual or contact your EMS captain.
