Polar Array explained in 60 Seconds | AutoCAD 2D-3D | Ira Edu-Tech
In this concise Hindi tutorial, the presenter demonstrates how to use AutoCAD's Polar Array tool to duplicate objects around a circular reference. Starting with a circle and a rectangle, they explain that when you need to arrange objects around a circular shape you choose the Polar option (as opposed to Rectangular). The command can be invoked via the PO shortcut or by clicking the Polar button. The workflow is shown step‑by‑step: select the object(s) to array, activate Polar Array, click the circle’s centre as the reference point, specify the number of instances (e.g., 12), and set the angular spacing either by total angle or by a per‑item angle (e.g., 1°). An optional "Rotated Item" setting is highlighted, which rotates each copy to follow the circular path. The video serves as a rapid, practical guide for creating evenly spaced circular patterns in AutoCAD.
