C4W1L02 Edge Detection Examples

The convolution operation is one of the fundamental building blocks of a convolutional neural network using edge detection as the motivating example. In this video you see how the convolution operation works. In previous videos I've talked about how the earlier layers of a neural network might detect edges and then the somewhat later layers might detect parts of objects and, and then even later layers maybe detect parts of complete objects like people's faces in this case. In this video you see how you can detect edges in an image. Let's take an example. Given a picture like that, for a computer to figure out what are the objects in this picture, the first thing you might do is maybe detect vertical edges in this image. So for example, this image has all those vertical lines where the railings are, as well as, you know, kind of vertical lines at the outline of these pedestrians. And so those get detected in this vertical edge detector output. And you might also want to detect horizontal edges. So for example, there's a very strong horizontal line where this railing is and that also gets detected by sort of roughly here. So how do you detect edges in an image like this? Let's look at an example. Here is a 6x6 grayscale image. And because this is a grayscale image, this is just a 6x6x1 matrix rather than 6x6x3 because there aren't separate RGB channels. In order to detect edges or let's say vertical edges. In this image what you can do is construct a three by three matrix. And in the pollens when the terminology of convolutional neural networks, this is going to be called a filter. And I'm going to construct a 3 by 3 filter or 3 by 3 matrix that looks like this. 111000 minus 1 minus 1 minus 1. Sometimes research papers would call this a kernel instead of a filter. But I'm going to use the filter terminology in these videos. And what you're going to do is take the six by six image and convolve it. And the convolution operation is denoted by this asterisk and convolve it with the 3 by 3 filter. One slightly unfortunate thing about the notation is that in mathematics the asterisk is the standard symbol for convolution. But in Python this is also used to denote multiplication or maybe element wise multiplication. So this asterisk has dual purposes. It's overloaded notation. But I'll try to be clear in these videos when this gives you 0 times 0 plus 5 times 0, plus 7 times 0. And then the rightmost column gives 1 times minus 1, 8 times minus 1, plus 2 times minus 1. And adding up these nine numbers will give you minus 5. And so I'm gonna fill in minus 5 over here, okay? And you can add up these nine numbers in any order. Of course, it's just that I went down the first row, then it's just that I went down the first column, then the second column, then the third. Next, to figure out what is this second element, you're gonna take the blue square and shift it one step to the right, like so. And let me get rid of the green marks here. And you're going to do the same element wise product and then addition. So you have 0 times 1, plus 5 times 1, plus 7 times 1, plus 1 times 0, plus 8 times 0, plus 2 times 0, plus 2 times negative 1, plus 9 times negative 1, plus 5 times negative 1. And if you add up those nine numbers, you end up with negative 4 and so on. If you shift this to the right, do the nine products and add them up, you get zero, and then over here you should get eight. And just to verify, you know, you have two plus nine plus five, that's 16. Then the middle column gives you zero, and then the rightmost column four plus one plus three times negative one, that's minus eight. So that's 16 on the left column, minus eight, and that gives you eight, like we have over here. Next, in order to get you this element in the next row, what you do is take the blue square and now shift it one down, so you now have it in that position. And again repeat the element wise product and then adding exercise. And if you do that, you should get negative 10 here. And if you shift it 1 to the right, you should get negative 2 and then 2 and then 3 and so on to then fill in all the rest of the elements of the matrix. And so to be clear, this -16 will be obtained by, you know, from this lower right 3 by 3 region. So a 6 by 6 matrix convolved with a 3 by 3 matrix gives you a 4 by 4 matrix. And these are images and filters. These are really just matrices of various dimensions. But the matrix on the left is convenient to interpret as a image, and the one in the middle we interpret as a filter. And the one on the right, you can interpret that as maybe another image. And this turns out to be a vertical edge detector. And you see why on the next slide. Before going on though, just one other comment, which is that if you implement this in a programming language, then in practice, most programming languages will have some different function rather than an asterisk to denote convolution. So for example, in the programming exercise you use or you implement a function called conf. If you do this in TensorFlow there's a function tf, nn, conf2d, and then other deep learning programming frameworks. In the Keras framework, which you see later in this course, there's a function called conf2d that implements convolution and so on. But all the deep learning frameworks that have good support for computer vision will have, you know, some function for implementing this convolution operator. So why is this doing vertical edge detection? Let's look at another example. So to illustrate this, we're going to use a simplified image. So here is a simple 6 by 6 image where the left half of the image is 10 and the right half is 0. If you plot this as a picture, it might look like this, where the left half the tens give you brighter pixel intensity values and the right half gives you darker pixel intensity values. I'm using that shade of gray to denote zeros, although maybe it could also be drawn as black. But in this image there's clearly a very strong vertical edge right down the middle of this image as it transitions from white to black or white to darker color. So when you convolve this with the 3 by 3 filter, and so this 3 by 3 filter can be visualized as follows. Where is lighter you have brighter pixels on the left and then this mid tones zeros in the middle and then darker on the right. What you get is this matrix on the right. So just to verify this math, if you want, um, this zero for example is obtained by taking the element wise products and then multiplying with this 3 by 3 block. And so you get from the left column 10 plus 10 plus 10 and then 0. So in the middle and then minus 10 minus 10 minus 10, which why you end up with 0 over here. Whereas in contrast if that 30 would be obtained from this, which you get from having, you know, 10 plus 10 plus 10 and then minus 0 minus 0, which is why you end up with a 30 over there. Now if you plot this rightmost matrix as an image, it will look like that where there's this lighter region right in the middle and that corresponds to is having detected this vertical edge down the middle of your six by six image. And in case the dimensions here seem a little bit wrong, you know that the detected edge seems really thick. That's only because we're working with very small images in this example. And if you're using, say a thousand by thousand image rather than six by six image, then you find that this does a pretty good job really detecting the edges, the vertical edges in your image. And in this example, this bright region in the middle is just the output image's way of saying that it looks like there's a strong vertical edge right down the middle of the image. And maybe one intuition to take away from vertical edge detection is that a vertical Edge is a 3x3 region, since we're using a 3x3 filter where there are bright pixels on the left and you don't care that much what's in the middle and dark pixels on the right. And the middle of the image is really, in this six by six image is really where, you know, there could be bright pixels on the left and dark pixels on the right. And that's why it thinks there's a vertical edge over there. And the convolution operation gives you a convenient way to specify how to find these vertical edges in an image. So you've now seen how the convolution operator works in the next video. You see how to take this and and use it as one of the basic building blocks of a convolutional neural network.
