How to Install Limb Stop on a 2020 Elite Ember

Nathan Brooks here from Elite Archery and I want to show you guys how to install the limb stop bracket on the module on the Elite ember.

Alright, so this is a really simple installment. You just take the bracket out of the package, take the silver nut that actually goes to the limb stop, drop it down in the slot on the bracket. Now I'm going to call this the front of the slot and this is the back of the slot. And the reason why is because you have two holes right here and I want to say the back is closest to those holes. The front is all the way away from it. So we're going to call this the front of the slot. Slide it all the way to the front. Take your limb stop and your limb stop set screw Allen wrench. Believe that's a 764 size Allen wrench. And just tighten that up. Okay. So once you got that tightened up, that's basically a really good handle that you can grab a hold of this to install the bracket here. So you take the bracket and it fits right down on the back of the module. There's two holes here, right there that are located on the back of the module. And there's two holes on the bracket and you have a long sloping edge that has a point to it. You can see that you got a long sloping edge that has a point. And then on the opposite side of this bracket you have kind of like a curve and a short edge. So we want to take the long edge with the point and drop it right on the long edge and point of the module. So it just drops right down in that position. These are, this is a Torx 15 size screw. So we're going to do the exact same thing on the opposite end of the bow. All done.

So from this point it's pretty simple. It's just a matter of setting the feel for the shooter. If a shooter wants more let off, you simply slide the limb stop back into the slot further. And you'll have to do the same thing top and bottom to make everything equal, keep the timing exactly the same.
