How to Solve the Temperature Imbalance Issue in Your House | HVAC Zoning Tips

26 Feb 2024 · 2 min

Watch on YouTube

2:26

In this monologue, Derek Cole explains why a single HVAC unit often fails to keep a two‑story house comfortable. He describes how heat naturally rises, making the upper floor warmer due to factors such as attic space, windows, and the lack of a comparable heat load downstairs. Because the thermostat is typically located on the lower level, the system over‑cools the downstairs area to satisfy the upstairs demand, leaving occupants downstairs feeling cold, especially at night or in summer. Cole argues that the most effective remedy is not necessarily adding a second furnace but creating a two‑zone system (zoning) that uses separate thermostats for upstairs and downstairs. This allows each zone to be controlled independently while still using the existing single unit, provided the home has a duct chase that can accommodate the additional zoning dampers. He notes that homes lacking a suitable duct chase may face installation challenges, but overall recommends zoning as a cost‑effective solution to temperature imbalance.

Chapters

The problem with one unit covering both is that you have different demands upstairs than you have downstairs. So when you look at a house and think about it, heat rises obviously, right? So when heat rises upstairs typically will be warmer than downstairs, right? So chances are, I've seen this before, the thermostat is downstairs. You have a unit that runs the whole house up and down. So to get upstairs comfortable, you then have to make downstairs freezing. When I first got married, we lived in an apartment that was 2 stories but had 1 unit. So I mean, when you went downstairs at nighttime, it was like you better put on like a big coat and everything because it can happen. Because upstairs you have more of a load than you have downstairs. Downstairs, heat rises. You also have the attic upstairs, so you have these forces you're going against. You have the attic, you have windows, you have upstairs heat rises and downstairs, of course, cold air falls and you don't have an attic downstairs. So you do in— and the crawl space is not that much of a heat load compared to an attic. So it's different demand. So how you solve that problem is either 2 units or what we've done quite a few times, which is zoning. You make downstairs one zone, you make upstairs one zone. It's very simple. If you have a unit that covers up and downstairs right now, you can very simply make it a two-zone system. That way you have a thermostat downstairs, you have the thermostat upstairs. You can keep it that temperature you want, you keep it that temperature you want, and they can make it work that way. So, uh, the challenge with some houses is that there is not that duct chase in the house for the duct to be run to have one unit for the whole home. But if you already have that, obviously that's available, but you just need to make it a zoning situation. I wouldn't get two units, I would just zone it upstairs, downstairs, and that will solve the problem. But until you do that, it is what it is. I mean, the thermostat downstairs, upstairs is warmer, and In the summertime, it's going to be— so you're just going to have to freeze it out downstairs and get upstairs as comfortable as possible.
