Install left and right mid wing VPU assemblies with the controller facing backwards. Route harnesses from VPUs along existing harness to the center frame. Attach opposite end of harness to the IMU located below and continue to the breakaway. Remove hose fold support. Add camera and bracket in place of support. Install inner wing cameras and brackets. Make sure to follow the installation manual for measurements. Remove roller nuts to install camera bracket. Pre mount the innermost camera bracket. Depending on optionality, a hole may need to be marked and drilled. Install after drilling, remove inner mirror bolts and add L bracket. Remove fold, stop bracket and install camera mount. Place fold stop over camera bracket and tighten. Install three outer wing cameras and brackets. Follow the installation manual as measurements vary. Install the breakaway camera assembly on the breakaway frame. Align. Using measurements in the manual. Mark and drill holes on both sides of the the breakaway frame. Check breakaway force following install, Install product and harness brackets on left and right frame. Route and tie up product hoses at hinge sections. Route camera harness from center vpu, then under wing camera brackets. Route the wing VPU camera harness the same way heading towards the breakaway to complete. Ensure no harness or hoses lay in front of cameras. Then update software and calibrate systems.
